Epoxy powder coating and baking in the oven. Optics in PMMA/PC guaranteed against UV rays and yellowing. Surge protection device up to 6kV. Insulation class II, IP66, and IK06 enclosure. Class II internal wiring and connections.
Anti-condensation valve. AISI 304 bolts with split spring washers, serrated and/or self-locking nuts. Replacement of internal components can be done using common tools. Access to components through the top opening. Connection to the network via an external cable with IP68 M20x1.5 connector (optional). Power supply, plate, and possible remote control (optional) interconnected with double-insulated rubber cables.
Power supply with nominal voltage 220-240 Vac, frequency 50/60 Hz. Efficiency ≥90% at full load, power factor cosϕ0.95. DALI interface (optional). LED lifespan >100,000 hours L90B10. Energy performance ≥A++. Color temperature from 2200k to 5700k, CRI>70. CE and ENEC certification. Fixture efficiency up to 174lm/W.
