Pegaso

LED lighting fixture used for tunnels, underpasses, industrial, road, metro, and railway applications.

Category: Tags: , , , , , , ,

Pegaso

LED lighting fixture used for tunnels, underpasses, industrial, road, metro, and railway applications.

Richiedi maggiori informazioni

The housing is made of a perforated extruded anodized aluminum heat sink, closed on both sides with powder-coated caps or AISI 304 stainless steel caps. The LED module is protected by a tempered glass resistant to impact IK07 and with IP66 protection rating. The directional optics with symmetric, asymmetric, rotosymmetric, or 2×2 reflection photometric solid, made of PMMA/PC, silicone, or aluminum, are guaranteed against UV rays and yellowing.

The projector is protected by a surge protection device up to 10kV.The lamp body is in Class II insulation. Internal wiring and connections are in Class II. PTFE anti-condensation valve or AISI 303 stainless steel, cable gland on PAor nickel-plated brass cap. Bolts and screws in AISI 304. Powder-coated steel or AISI 304 mounting bracket. Integrated power supply inside the lamp body. LED module composed of aluminum substrate with high-efficiency LEDs. It is possible to install optional remote control inside the lamp body. Power supply with nominal voltage 220-240 Vac wired inside or integrated, frequency 50/60 Hz. Efficiency ≥90% at full load, power factor Cosφ ≥ 0.95.

The operating temperature of the lamps ranges from -40 to +55 °C. The control system is managed by the 1-10V control module (optional).

LED lifespan >100,000 hours L90B10. Energy performance ≥A++. Color temperature from 3000k to 5700k, CRI >72. Luminaire efficiency up to 155lm/W. CE and  ENEC certification.
